Powerwerx
Solid Hookup Wire (300 Volt) (Gauge: 20 - Length: 5000 ft., Color: Orange) Wire-SO-20-03-5000
SKU: SKU-8B8664AA133A
List Price: CA$555.14
Price includes all taxes
In Stock — Ready to Dispatch
-
Shipping calculated at checkout · Delivery timing is shown in the shipping policy
-
30-Day Returns · Eligibility rules apply
-
Secure Checkout · SSL encrypted payment
Eligible items may be returned within 30 days. See the return policy for conditions.
Payment Method
Cash on Delivery — pay when your order is delivered.
Product Details
About this product
Description
Voltage Rating: 300 VAC Gauge (AWG) Conductor Diameter Finished Wire Diameter Max. KG/Km 18 .0402 1.02 .0717 1.82 6.77 22.2 6.70 9.97 20 .0320 .813 .0635 1.61 10.7 35.2 4.64 6.91 22 .0253 .643 .0568 1.44 18.1 59.4 3.39 5.04 24 .020 .511 .0516 1.31 28.7 94.2 2.47 3.68 26 .0159 .404 .0472 1.20 45.8 150 1.86 2.75. Internal wiring of panels and meters. Internal appliance and point to point electronic wiring. Resistant to moisture, oil solvents, and fungus. Passes VW-1 Vertical Flame Test. Solid tinned copper. UL Listed, UL Style 1007. CSA Listed, CSA TR-64. suited for Hobbyist. Conductor: Fully annealed tinned solid copper per ASTM B-33 Insulation: -grade, color-coded PVC Temperature Range: -20癈 to +105癈 (-4癋 to +221癋) Compliances: UL Style 1007 - 80癈, UL Style 1569 - 105癈, CSA TR-64 - 90癈, Designed to meet UL VW-1 Vertical Wire Flame Test, RoHS Compliant Applications: Internal wiring of electrical and electronic equipment. Internal wiring of panels and meters. Point-to-point wiring. Voltage Rating: 300 VAC Gauge (AWG) Conductor Diameter Finished Wire Diameter Max. Resistance (DC at 20癈) Ohm/per Nom. Weight Inch mm Inch mm 1000-ft Km LBS./1000 ft. KG/Km 18.0402 1.02.0717 1.82 6.77 22.2 6.70 9.97 20.0320.813.0635 1.61 10.7 35.2 4.64 6.91 22.0253.643.0568 1.44 18.1 59.4 3.39 5.04 24.020.511.0516 1.31 28.7 94.2 2.47 3.68 26.0159.404.0472 1.20 45.8 150 1.86 2.75. Passes VW-1 Vertical Flame Test. Solid tinned copper. CSA Listed, CSA TR-64. UL Listed, UL Style 1007. Great for Hobbyist.
Key Features
- Internal appliance and point to point electronic wiring.
- Resistant to moisture, oil solvents, and fungus.
- KG/Km 18.0402 1.02.0717 1.82 6.77 22.2 6.70 9.97 20.0320.813.0635 1.61 10.7 35.2 4.64 6.91 22.0253.643.0568 1.44 18.1 59.4 3.39 5.04 24.020.511.0516 1.31 28.7 94.2 2.47 3.68 26.0159.404.0472 1.20 45.8 150 1.86 2.75.
- Conductor: Fully annealed tinned solid copper per ASTM B-33 Insulation: -grade, color-coded PVC Temperature Range: -20癈 to +105癈 (-4癋 to +221癋) Compliances: UL Style 1007 - 80癈, UL Style 1569 - 105癈, CSA TR-64 - 90癈, Designed to meet UL.
- Weight Inch mm Inch mm 1000-ft Km LBS./1000 ft.
- Voltage Rating: 300 VAC Gauge (AWG) Conductor Diameter Finished Wire Diameter Max.
Shipping & Returns
- Shipping calculated at checkout
- Eligible returns within 30 days
- See the shipping policy for current delivery timing
