Sealmaster SFT-20T Flange Block Bearings

Description

For added protection, flingers on the inner ring deflect contaminants away from the seals. Low-friction felt labyrinth seals on both sides of the bearing retain lubricant applied at manufacture and help keep contaminants out. The double-sealed, deep-groove ball bearing cartridge insert in the housing is rated "standard duty" for applications with moderate radial loads and light to moderate thrust or combination loads. A pin and dimple anti-rotation rivet on the outer ring prevents rotation of the ring in the housing, reducing heat buildup and prolonging the bearing life. The bearing housing replaces the need for a casting or weldment to position the bearing securely for reliable operation, and its design determines the type of insert bearing. A locking pin-and-dimple system feeds oil through the bearing and prevents outer-ring rotation within the housing. This self-aligning bearing has a convex sphered outer surface that compensates for misalignments. The bearing is made of vacuum degassed 52100 chrome steel, and the inner and outer races are coated with black oxide for corrosion resistance. The bearing locks onto the shaft with a fluoropolymer-coated concentric locking clamp collar (Skwezloc) and two Torx head cap screws for 360-degree holding power. It is designed for mounting onto bearing surfaces perpendicular to the shaft axis. It is equipped with a grease fitting on the outer surface for reapplying lubricant. Insert bearings us.

Key Features

• It is designed for mounting onto bearing surfaces perpendicular to the shaft axis.
• The one-piece housing has machined foot pads and is made of solid cast iron for rigidity and vibration damping.
• The bearing is made of vacuum degassed 52100 chrome steel, and the inner and outer races are coated with black oxide for corrosion resistance.
• It is equipped with a grease fitting on the outer surface for reapplying lubricant.
• Flanged bearing units are suitable for use in industrial and commercial applications including conveyors, fans and blowers, construction machinery, and processing equipment, among many others.Mounted bearings combine a bearing mounted.
• The inner ring is extended to provide extra shaft support.
